How To Create Family Tree Using HTML and CSS ?

uday

Hi Guys., Do you wanna create a family tree ? Here you go with simple HTML and CSS code

HTML :

<!--
We will create a family tree using just CSS(3)
The markup will be simple nested lists
-->

<div class="tree">
	<ul>
		<li>
			<a href="#">Parent</a>
			<ul>
				<li>
					<a href="#">Child</a>
					<ul>
						<li>
							<a href="#">Grand Child</a>
						</li>
					</ul>
				</li>
				<li>
					<a href="#">Child</a>
					<ul>
						<li><a href="#">Grand Child</a></li>
						<li>
							<a href="#">Grand Child</a>
							<ul>
								<li>
									<a href="#">Great Grand Child</a>
								</li>
								<li>
									<a href="#">Great Grand Child</a>
								</li>
								<li>
									<a href="#">Great Grand Child</a>
								</li>
							</ul>
						</li>
						<li><a href="#">Grand Child</a></li>
					</ul>
				</li>
			</ul>
		</li>
	</ul>

CSS:

/*Now the CSS*/

* {margin: 0; padding: 0;}


.tree ul {
	padding-top: 20px; position: relative;

	transition: all 0.5s;
	-webkit-transition: all 0.5s;
	-moz-transition: all 0.5s;
}


.tree li {
	float: left; text-align: center;
	list-style-type: none;
	position: relative;
	padding: 20px 5px 0 5px;

	transition: all 0.5s;
	-webkit-transition: all 0.5s;
	-moz-transition: all 0.5s;
}


/*We will use ::before and ::after to draw the connectors*/


.tree li::before, .tree li::after{
	content: '';
	position: absolute; top: 0; right: 50%;
	border-top: 1px solid #ccc;
	width: 50%; height: 20px;
}
.tree li::after{
	right: auto; left: 50%;
	border-left: 1px solid #ccc;
}


/*We need to remove left-right connectors from elements without
any siblings*/
.tree li:only-child::after, .tree li:only-child::before {
	display: none;
}


/*Remove space from the top of single children*/
.tree li:only-child{ padding-top: 0;}


/*Remove left connector from first child and
right connector from last child*/
.tree li:first-child::before, .tree li:last-child::after{
	border: 0 none;
}
/*Adding back the vertical connector to the last nodes*/
.tree li:last-child::before{
	border-right: 1px solid #ccc;
	border-radius: 0 5px 0 0;
	-webkit-border-radius: 0 5px 0 0;
	-moz-border-radius: 0 5px 0 0;
}
.tree li:first-child::after{
	border-radius: 5px 0 0 0;
	-webkit-border-radius: 5px 0 0 0;
	-moz-border-radius: 5px 0 0 0;
}


/*Time to add downward connectors from parents*/
.tree ul ul::before{
	content: '';
	position: absolute; top: 0; left: 50%;
	border-left: 1px solid #ccc;
	width: 0; height: 20px;
}


.tree li a{
	border: 1px solid #ccc;
	padding: 5px 10px;
	text-decoration: none;
	color: #666;
	font-family: arial, verdana, tahoma;
	font-size: 11px;
	display: inline-block;

	border-radius: 5px;
	-webkit-border-radius: 5px;
	-moz-border-radius: 5px;

	transition: all 0.5s;
	-webkit-transition: all 0.5s;
	-moz-transition: all 0.5s;
}


/*Time for some hover effects*/
/*We will apply the hover effect the the lineage of the element also*/
.tree li a:hover, .tree li a:hover+ul li a {
	background: #c8e4f8; color: #000; border: 1px solid #94a0b4;
}
/*Connector styles on hover*/
.tree li a:hover+ul li::after,
.tree li a:hover+ul li::before,
.tree li a:hover+ul::before,
.tree li a:hover+ul ul::before{
	border-color:  #94a0b4;
}

That's It. Very Simple right. I hope you guys enjoyed it😉.

Thanks

Yours UDAY
